※6/7MPPTSAkıllı teşhis※Yüksek verimlilik %99'a kadar※Yerel WIFI bağlantısı※Satır izleme※AC&DC II tip SPD※AFCl koruması※Verilerin 25 yıla kadar saklanması※DC tarafı 2 in 1 bağlantısı etkinleştirildi
MIN 7000~10000 TL-X
※Maksimum verimlilik 98.1%2/3 MPP izleyicileri ※DC tarafında II tip SPD ※İhracat kontrolünü destekliyor ※Dokunmatik tuş ve OLED ekran
Ürün Parametresi
Veri sayfası
MID 6KTL3-XL
MID 8KTL3-XL
MID 10KTL3-XL
MID 11KTL3-XL
MID 12KTL3-XL
Girdi Verileri
Max.DC gücü
65000W
10400W
13000W
13000W
15600W
Max.DC voltajı
800V
Başlangıç voltajı
250V
MPPT gerilim aralığı
160-800V
Nominel voltaj
360V
MPPT başına maksimum giriş akımı
25A
Çıktı (AC)
Değişimsel çıkış gücü
6000W
8000W
10000W
11000W
12000W
Max. AC görünen gücü
6600VA
8800VA
11100VA
12100VA
13300VA
Maks. çıkış akımı
16.5A
22.1A
27.8A
30.3A
30.3A
AC nominal voltajı
133V/230V
AC şebeke sıklığı
50Hz/60Hz
Maksimum verimlilik
98.8%
Veri sayfası
MIN 7000TL-X ((E)
MIN 8000TL-X (((E)
MIN 9000TL-X
MIN 10000TL-X
Girdi Verileri
Max.DC gücü
12000W
12000W
13500W
15000W
Max.DC voltajı
600V
Başlangıç voltajı
100V
MPPT gerilim aralığı
60-550V
Nominel voltaj
360V
MPPT başına maksimum giriş akımı
13.5A/27A
Çıktı (AC)
Değişimsel çıkış gücü
7000W
8000W
9000W
10000W
Max. AC görünen gücü
7000VA
8000VA
9000VA
10000VA
Maks. çıkış akımı
33.5A
33.5A
43A
45.5A
Nominel AC voltajı (( aralığı*)
Varsayılan: 240V bölünmüş fazlı, isteğe bağlı:208V ve 240V tek fazlı, 183-228@208V 211-264V@240V
